SKX-LD-LH22 Series 50W | 100W | 150W | 200W | 250W LED Street Lights
SKX-LD-LH22 Series 50W~250W LED Street Lights
P/N: SKX-LD-LH22 Series
Power: 50W /100W / 150W / 200W / 250W
Input Voltage: AC 90-305Vac; 50/60Hz
Luminous efficiency: upto 150lm/W
Die-cast Aluminum housing
Lifetime: 50,000 hrs
IP65 CE
Product Detail
SKX-LD-LH22 Series LED Street Light (50-250W)
Premium-Grade Adjustable Street Lighting Solution
Technical Specifications
1. Electrical & Optical Performance
| Parameter | 50-100W | 100-150W | 150-200W | 200-250W |
|---|---|---|---|---|
| Input Voltage | AC90-305V, 50/60Hz | |||
| Power Factor | >0.95 | |||
| Luminous Efficacy | 110-150 lm/W | |||
| LED Type | 3030/5050 SMD (Lumileds/CREE) | |||
| LED Count | 60-120pcs | 120-180pcs | 180-240pcs | 240-300pcs |
| CCT Options | 2700K-6000K (Customizable) | |||
| CRI | >80 (Standard) | |||
| Beam Angle | 70°×140° (Type III Standard) |
2. Mechanical Design
| Feature | Specification |
|---|---|
| Housing Material | ADC12 Die-cast Aluminum |
| Lens Material | 5mm Tempered Glass + PMMA Reflector |
| Thermal Design | 96W/M.K Conductivity |
| Protection Rating | IP65 (Enhanced sealing) |
| Wind Resistance | 60m/s (216km/h) |
3. Dimensions & Weight
| Model | Fixture Size (L×W×H) | Package Size (L×W×H) | Weight |
|---|---|---|---|
| 50-100W | 500×300×100mm | 525×330×130mm | 5.8kg |
| 100-150W | 500×300×100mm | 625×330×130mm | 7.2kg |
| 150-200W | 500×300×100mm | 675×330×130mm | 8.5kg |
| 200-250W | 500×300×100mm | 725×330×130mm | 10.1kg |
4. Thermal Performance
-
Max. Junction Temp: <63°C at 45°C ambient
-
Hot-Cold Zone Separation: Patented design
-
Heat Sink Area: 15% larger than industry standard
Key Features
✔ Precision Optical System
-
Asymmetric light distribution (Type III-V available)
-
UGR<19 anti-glare technology
✔ Durability Enhanced
-
1,500h salt spray tested housing
✔ Smart Control Ready
-
Built-in 0-10V/DALI/PWM interfaces
-
Optional motion/light sensors
✔ Installation Flexibility
-
360° adjustable mounting bracket
-
Tool-less maintenance access
Packaging & Logistics
| Model | Units/CTN | 20'GP Qty | 40'HQ Qty | Pallet Config |
|---|---|---|---|---|
| 50-100W | 1 | 1,450 | 3,500 | 30pcs/pallet |
| 200-250W | 1 | 1,050 | 2,550 | 18pcs/pallet |
Packaging Features:
-
Military-grade triple-layer cartons
-
Custom EPS foam moldings
Certifications & Warranty
-
Safety: CE, ENEC, IEC 60598-1
-
EMC: EN 55015, EN 61000-3-2
-
Environmental: RoHS, REACH, TUV
-
Warranty: 6 years (extendable)
Recommended Applications
Value-Added Services
✅ Free DIALux lighting simulations
✅ Custom photometric reports
✅ On-site technical support
*Note: All dimensions in millimeters. 5050 SMD reduces wattage by 10-15%.*
