SKX-LD-M-XH18 Series 50W | 100W | 150W | 200W | 250W | 300W LED Street Lights

SKX-LD-M-XH18 Series 50W~300W LED Street Light – Weather‑Proof & Smart‑Control Outdoor Fixture

P/N: SKX-LD-M-XH18 Series

Power: 50W / 100W /150W / 200W / 250W / 300W

Input Voltage: AC 50-500Vac; 50/60Hz

Luminous efficiency: 150-170lm/W

Die-cast Aluminum housing

Lifetime: 60,000 hrs

IP65 IK08 CE

Send Email

Product Detail

LED Adjustable Street Light SKX-LD-M-XH18 (50–300W)
Key Features
Dynamic Angle Adjustment
Unique pivoting arm design allows LED head adjustment with 30°, 60° tilt (up/down) and 30°, 60° swivel (left/right) for precise directional control.

Superior Energy Efficiency
Up to 170 lm/W system efficacy — reduces energy costs by 70% compared to traditional lighting.

Enhanced Durability
Robust die-cast aluminum housing (ADC12) with anti-corrosion finish; IP65-rated for harsh environments and IK08 impact resistance.

Modular Scalability
Power scales from 50W to 300W by adding/removing LED modules; uniform width and thickness across all models.

Advanced Optics
Customizable beam patterns (Type II, III, V) with anti-glare lenses for optimal light distribution.

Smart-Ready Integration
Optional 0–10V/DALI dimming, motion sensors, or IoT connectivity for adaptive lighting control.

Technical Specifications

Parameter	Details
Model No.	SKX-LD-M-XH18
Power Range	50W / 100W / 150W / 200W / 250W / 300W
Input Voltage	AC 50–500V, 50/60Hz
Power Factor	>0.95
Luminous Efficacy	150–170 lm/W (system)
LED Chips	Lumileds / CREE / Customizable
Material	ADC12 Die-cast Aluminum
CCT	2700–6500K (Adjustable or Customizable)
CRI	>70 / 80
Driver Options	Meanwell / Inventronics / Customizable
Lifetime	60,000 hours
IP Rating	IP65
Adjustment Range	Tilt: ±30°, ±60° / Swivel: ±30°, ±60°
Fixture Dimensions (L×W×H)	All Models: 330mm (W) × 95mm (H) × Length: 50W: 360mm / 100W: 440mm / 150W: 520mm / 200W: 600mm / 250W: 680mm / 300W: 760mm
Package Dimensions (L×W×H)	50W: 360×350×110mm / 100W: 440×350×110mm / 150W: 520×350×110mm / 200W: 600×350×110mm / 250W: 680×350×110mm / 300W: 760×350×110mm

Notes

Angle Flexibility: Adjustable arm ensures optimal light placement for complex road layouts or obstacles.
Unified Design: Only length varies by power (W:330mm, H:95mm fixed).
Customization: Tailor CCT, beam angles, drivers, and smart controls to project needs.
Certifications: Complies with IEC, EN, and RoHS standards.
Warranty: 6-year warranty on LED modules and drivers.
