30W/40W All In One SKX-S-FY24 Series High-Power Solar Street Light
30W/40W All In One SKX-S-FY24 Series High-Power Solar Street Light for Residential & Commercial Use
P/N: SKX-S-FY24 Series
Power: 30W/40W
60W~80W Bifacial solar panel
Microwave motion sensor
LED SMD 5050
Aluminum 6063 frame
LiFePO4 battery
MPPT controller
Product Detail
SKX-S-FY24 LED ALL IN ONE SOLAR STREET LIGHT
Product Overview
This product is a patented solar street light featuring a high-purity aluminum housing and PC lens, designed for efficient heat dissipation and optimized optical performance. Its modular structure ensures easy installation and maintenance, making it suitable for various outdoor lighting applications.
Key Advantages
-
Patented Design: Streamlined profile with enhanced heat dissipation.
-
Premium Materials:
-
Housing: High-strength, corrosion-resistant 6063 aluminum alloy (IP65 rated).
-
Lens: Impact-resistant PC material with >90% light transmittance.
-
-
High Efficiency Lighting:
-
Light Source: 5050 SMD / CREE / BRIDGELUX / PHILIPS chips (optional), luminous flux 4800LM~5400LM.
-
Color Temperature: 5700K (customizable), CRI >70.
-
-
Smart Energy Management:
-
MPPT controller (12A), improving charging efficiency by 30%.
-
LiFePO4 battery with a lifespan of up to 10 years.
-
-
Flexible Configuration:
-
Dual-sided solar panels (60W/80W monocrystalline), adjustable angle (0°~90°).
-
Modular design for easy replacement of light source and battery.
-
Technical Specifications
| Model No. | SKX-S-FY80 (60W) | SKX-S-FY80 (80W) |
|---|---|---|
| Solar Panel | 18V 60W Monocrystalline | 18V 80W Monocrystalline |
| Battery Capacity | LiFePO4 3.2V 60AH | LiFePO4 3.2V 80AH |
| Controller Type | MPPT 12A | MPPT 12A |
| Luminous Flux | 4800LM | 5400LM |
| LED Type | 5050 SMD LED | 5050 SMD LED |
| Material | Aluminum 6063 | Aluminum 6063 |
| CCT (Color Temperature) | 5700K (Customizable) | 5700K (Customizable) |
| CRI (Color Rendering Index) | >70 | >70 |
| Lifespan | 50,000 hours | 50,000 hours |
| IP Rating | IP65 | IP65 |
| Beam Angle | 80°~160° | 80°~160° |
| Operating Temperature | -20°C ~ +65°C | -20°C ~ +65°C |
| Lighting Duration | 12 hours/day | 12 hours/day |
Application Areas
-
Urban arterial roads, commercial plazas, and industrial zones.
-
Outdoor lighting for highways, stations, docks, and similar locations.
Additional Features
-
Rotatable Module: Adjustable solar panel angle (0°~90°) for optimal sunlight exposure.
-
Aluminum Bracket: Reinforced holder with Q304 screws for secure installation.
-
Integrated Design: Combines light source and battery module for easy disassembly and maintenance.
Note: Specifications are subject to customization based on project requirements.
